的用途与简洁/Brief Introduction：

该选果机型选取层次性三通管包装阀，使用到水剂和膏霜类的产品的包装，特别的对高凝固点货品（如浓酱、朝天椒酱、番茄酱、种衣剂、微乳剂、漂浮剂等）的实际效果非常比较突出，且高精准性强。该选果机型选取PLC可和程序编写设定，并配6厘米接触屏人机对战软件界面设计，颁布重新化化进瓶，重新化化包装，重新化化出瓶，家电，气动弹簧元构件均选取知名的品牌，切实保障了出彩的水平和男人持久平稳的能力。本设施机器设备形式容易，进行操作便宜，是中国大陆非常理想的专门针对高凝固点货品的包安置施机器设备。该选果机型配发了制止漏滴与不锈钢金属拉丝的包装闷头，切实保障包装终止后无漏滴，无不锈钢金属拉丝。Filling valve, the machine USES special tee is suitable for the filling agent and cream products, especially for high viscosity material (such as thick sauce, chili sauce, tomato sauce, indicated, micro emulsion, suspending agent, etc.) of the effect is obvious, and high precision. The machine USES PLC programmable control, with 6 inch touch screen man-machine interface system, implements the automatic into the bottle, automatic filling, automatic bottle, electric, pneumatic components adopt international brand, to ensure that the performance of the outstanding quality and lasting stability. This equipment has simple structure, convenient operation, is the ideal filling equipment for high viscosity material. The machine is equipped with prevent drip with wire filling cocks, ensure filling after the completion of a drip-tight, no drawing.

优缺点/Characteristic：

◆操纵系统控制的——采用了三菱PLCPLC操纵系统控制的，装灌极量随时调节。Control system adopt mitsubishi PLC control system, filling dose random tweaks◆工作画面——6英尺彩屏手触式工作画面，主观简单易行、的安全正规Interface - 6 inches color hand touch interface operation, intuitive and simple, safe and reliable◆用途提高——排料有防漏滴平衡装置，可按照物品优点配备下潜灌装线用途。（此用途能够使用的）Improvements - blanking drip tight device, according to the material properties have diving filling function. (this function can be chosen)◆机器设备元器件封装——均分为国际英文闻名店牌，保持机器设备的防护牢靠、更准高朝；Electrical components adopt international famous brand, to ensure the equipment safe and reliable, high accuracy;◆机诫元件——机械设备元件均分为高质量304不锈304不锈钢作,如不都要触及原材料是可以分为316L另记费用。Mechanical parts, machine parts are made of high quality 304 stainless steel material can be used if necessary contact 316 l in extra costs.◆记数论文检测——实时时间记数，对办公产品的生产数量客观发生变化。Counting test, real-time, intuitive reflect the yield of work.◆罐装检则——无瓶不灌、瓶数不足够不灌Bottle filling test - no bottle no filling, not enough◆定期维护与保养情况发生——超声波焊接机贴合GMP特殊要求，可轻轻松松拆换、洁净定期维护与保养。Maintenance - the machine is in line with the GMP requirements, easy disassembly, cleaning maintenance.◆互换品种——修改包装品种时，只需要十分简单调准，枯燥拿下。Changing specifications - change the filling specifications, simply adjust, easy fix.◆节能绿色配选——配选了节能绿色整体布局完成后，使机械设备的操控工作环境越来越干净安全卫生。（此节能绿色配选能够 配选）Environmental protection configuration, configuration framework of environmental protection, make the operation of the machine environment more clean sanitation. (the environmental protection configuration can be selected)

能力性能指标/technical parameters：

灌装设备头数The number of filling head	8头（可以选择4、6、8、10、1多个装罐头）8 head (option𝓀al 4, 6, 8, 1💝0, 12 filling head)
符合瓶径 Applicable bottles Drive	Ф33-Ф100 mm
量值溯源表面粗糙度measure precision	±1%
罐装储存量Canned capacity	150-1000ml
分娩性能Production Capacity	2400-4000瓶/时间2400-4000   bottles per hour
气源压力bleed pressure	0.7-0.9mpa
电    源Power Supply	380 伏/50 HZ
总 功 率The total power	0.5 kw
外形尺寸 boundary dimension	6000×850×1800 mm
重    量Weight	500kg
